What Creative Audio says

If you’re like most, you plug your turntable into the ‘Phono’ input on your amplifier or receiver and don’t think any more about it. To do so would be doing a great disservice to your record collection, however. That ‘Phono’ input is connected to a special device called a phono preamplifier and it is actually a critical component in the vinyl replay chain. The integrated phono preamplifier included in most amplifiers and receivers is of very basic quality. A dedicated, outboard phono preamp such as the NAD PP 2e offers an immediate and significant improvement in sound quality. The NAD PP 2e has always been a huge favourite at Creative Audio. It is one of those rare budget hi-fi components that is a true overachiever. For an entry-level turntable rig, the NAD PP 2e is essential.

What NAD says

Offering superb measured and sonic performance, NAD’s two simple solutions, the PP 4 Digital Phono/USB Preamplifier, available in Winnipeg at Creative Audio, makes it easy to add phono to many of today’s stereo amplifiers and AV receivers that have either eliminated the phono input or included a low quality circuit for attaching your turntable. As part of NAD’s commitment to the environment, the PP 4 features a more efficient “green” power supply that reduces power consumption. The PP 4 goes one step further with a USB interface, shielded USB cable and recording level control which reduces noise and improves the analogue-to-digital conversion process. The PP 4’s Auto Power Down feature saves energy by automatically powering the PP 4 to OFF when not in use.

Our PP 4 Digital Phono/USB Preamplifier enables you to digitise your treasured vinyl collections to a PC or Mac. It features inputs for both MM (moving magnet) and MC (moving coil) types for a wide variety of phono cartridges, and there is a line input to allow for the transfer of cassette tapes. The PP 4 also includes VinylStudio Lite Software for ripping LPs and burning audio CDs. The PP 4 Phono-to-USB Preamp offers a complete hardware and software solution with exceptional flexibility to record from LP or tape.

PP 4 VinylStudio Lite

The PP 4 comes with Mac and PC compatible version of AlpineSoft’s VinylStudio Lite ripping software is included with your new PP-4. With VinylStudio Lite you can:

  • Rip LPs into WAV files

  • Split Tracks

  • Burn CDs

  • Record Disks

  • Look up Song Titles

  • Handle File Management

To upgrade to the fully featured version of VinylStudio, please visit AlpineSoft’s own website and purchase the most intuitive software available for ripping LPs and burning CDs. VinylStudio’s powerful audio cleanup tools (you can trial these in VinylStudio Lite) can be used to remove clicks and pops restoring your songs to like new condition.

More about the NAD PP 4

Dimensions: 5 5/16" x 1 15/16" x 2 7/8" (WxHxD)

MC Input
Input Impedance (R and C): 100 Ohm + 180pF
Gain at 1kHz: 58dB
Input Sensitivity (ref. 200mV output): 0.38mV
Signal to Noise Ratio: 78dB (A weighted, with cartridge connected)
Input Overload (20Hz/1kHz/20kHz): 0.65/6.5/60mV
Rated Distortion (THD 20Hz – 20kHz): <0.03%
RIAA Response Accuracy: ±0.3dB
Infrasonic filter: -14dB (5Hz) -3dB (10Hz)
Digital output (USB): 16 bit linear PCM
Sampling frequency: 48kHz
Dynamic range: 86dB

MM Input
Input Impedance (R and C): 47 kilohm + 200pF
Gain at 1kHz: 35dB
Input sensitivity (ref. 200mV output): 5mV
Signal to Noise Ratio: 78dB (A weighted, with cartridge connected)
Input overload (20Hz/1kHz/20kHz): 10/100/900mV
Rated Distortion (THD 20Hz – 20kHz): <0.03%
RIAA response accuracy: ±0.3dB
Infrasonic filter: -14dB (5Hz) -3dB (10Hz)
Digital output (USB): 16 bit linear PCM
Sampling Frequency: 48kHz
Dynamic range: 89dB
Record Level: 0dB to -6dB

Output Impedance: 100 Ohm
Maximum Output Level: 5.3V

Availability: Normally stocked
